Product introduction
This product is an industrial professional dispatching console developed by Everett. It is made of aluminum magnesium alloy, light in volume and beautiful in shape. It is firm, shockproof, moisture-proof, dust-proof, high temperature resistant, multi slot and easy to expand. The whole machine is equipped with a high brightness LCD screen, integrated with industrial low power consumption embedded duty, supports CF and HDD, and has multiple I/O interfaces; Capacitive touch screen, with adjustable brightness and contrast, and standby energy-saving mode. All I/O ports are vertically led out from the lower part of the rear frame of the chassis, which brings great convenience to customers in application and maintenance. The whole machine can reach the military level standard. Generally, it is used together with the company's network dispatching server to realize single call, group call, temporary group call, broadcast and other functions; If the terminal is an IP phone terminal with camera or associated with the corresponding camera, the video call function can be realized.
The equipment is equipped with two master dispatching telephone stations, which adopt standard SIP protocol, support the basic functions of commonly used IP phones, support camera linkage, and support handsfree. Each telephone station is equipped with an 8.5W speaker, which supports automatic call answering and public address. With our server, it can realize single call, group call, group call, monitoring, forced disassembly, broadcast call, multi-party conference, GPS electronic map, video call and other functions.
Product Functions
1. Dispatching telephone station
It is divided into left phone and right phone. Both phones have hands-free and key dialing functions to realize hands-free emergency broadcast calling function
2. Main control interface
It can realize point-to-point touch one key call, monitoring, forced insertion, forced disassembly, temporary group call and other operations
3. Multi party meeting
A conference group can be established to invite participants. For example, the SIP extension supports video function, which can realize video conference
4. Broadcasting function
The designated extension and group can be broadcasted through broadcasting (audio file, on-site call through dispatching station, text to audio)
5. Emergency plan
The contents of corresponding plans can be added according to the specific situation to realize the functions of fire linkage, video linkage, on-site broadcasting, etc
6. Alarm processing
The center can immediately lock the alarm point according to the triggered alarm, alarm in time and keep all alarm records
7. Video monitoring
The camera can be connected to display the camera image on the console in real time and record and capture the real-time image
8. Collaborative Tasks
Tasks can be assigned to multiple employees to complete tasks together, and employees can submit records through the app after completion
9. Electronic map
The electronic map function can easily and clearly see the distribution of terminals or APP real-time positioning that have been configured in advance at the designated location. It supports radio selection of calls to designated terminals and other requests, as well as box selection and circle selection of multiple terminals to initiate calls, broadcasts and other requests
product mix
